Safety Gang Agitation Points

Safety Gang Agitation Points

Safety Gangs / Agitation Points can be used in conjunction with any Gang Slats in the range and provides trouble free access to the slurry tank. They provide easy access to either mix or draw the slurry out of the tank.

Concrete Safety

This product allows for easy yet safe access to the slurry tank to allow for the agitation and spreading of slurry. Depending on your needs and requirements, these can come galvanised grills, concrete inserts or covers.

Download Brochure
For further information regarding Safety Gang Agitation Points Please contact a member of our agriculture Sales Team on 028 2565 2566, Ext 1
Make an Enquiry
  • Features & Specifications
  • Product Dimensions

    Agitation Point Dimensions

    Width
    (mm)
    Depth
    (mm)
    Length (mm) Opening
    (mm)
    Loading Capacity
    1100* 178 (7") 1525(5') - 3960 (13')
    in 150mm increments
    900 x 790 Axle Loading up to 6.5 ton
    1290 178 (7") 2440 (8') - 4572 (15')
    in 150mm increments
    1000 x 945 Axle Loading up to 6.5 ton
    1290 250 (10") 2745 (9') - 4875
    (16') in 305mm increments
    1000 x 945 Axle Loading up to 6.5 ton
    1290 250 (10") 5000 (16'4") 1000 x 945 Axle Loading up to 6.5 ton

    *Solid Safety Slats available

    Complete with Concrete Inserts Concrete & Galvanised Grid. Galvanised Inserts available on request. We manufacture a range of agitation points. All our sizes can be found in the table above.

Agitation Point Dimensions

Width
(mm)
Depth
(mm)
Length (mm) Opening
(mm)
Loading Capacity
1100* 178 (7") 1525(5') - 3960 (13')
in 150mm increments
900 x 790 Axle Loading up to 6.5 ton
1290 178 (7") 2440 (8') - 4572 (15')
in 150mm increments
1000 x 945 Axle Loading up to 6.5 ton
1290 250 (10") 2745 (9') - 4875
(16') in 305mm increments
1000 x 945 Axle Loading up to 6.5 ton
1290 250 (10") 5000 (16'4") 1000 x 945 Axle Loading up to 6.5 ton

*Solid Safety Slats available

Complete with Concrete Inserts Concrete & Galvanised Grid. Galvanised Inserts available on request. We manufacture a range of agitation points. All our sizes can be found in the table above.

Delivery

All slats are CE Marked – Manufactured to EN 12737.
Declaration of Performance
Storage and Handling Instructions

For further information regarding Safety Gangs/Agitation Points please contact a member of our Agri sales team on 028 2565 2566, Ext 1
